Specifications

• Dynamic Friction Torque (Nm): 320.0
• Maximum RPM: 2,000
• Outer Diameter (B) mm: 264.00
• Flange dimension (C1) mm: 290.00
• Overall Height (L) mm: 64.00
• Stator Height (H) mm: 51
• Collar Diameter (F) mm: 100
• Mass (kg): 18.700
• Total Work Performed ET (J): 20×10⁸
• Armature Pull-in Time (seconds): 0.115
• Heat Resistance Class: B
• Coil Voltage (V): DC24
• Coil Wattage (W): 60
• Coil Resistance (ohms): 10
