Specifications

• Static Friction Torque (Nm): 4.0
• Maximum RPM: 5,000
• Outside Diameter (A) mm: 96.00
• Bolt Circle Diameter (B) mm: 86.00
• Armature Pull-in Time (seconds): 0.04
• Backlash: 1.18
• Overall Height (K) mm: 41.0
• Mass (kg): 1.300
• Total Braking Energy (J): 3.5×10⁷
• Coil Resistance (ohms): 26
• Coil Wattage (W): 23
• Function: Power Off - Brake Engaged
• Standard Bore Sizes: 14
