Specifications

• Static Friction Torque (Nm): 1.3
• Maximum RPM: 6,000
• Outside Diameter (A) mm: 48.00
• Bolt Circle Diameter (B) mm: 42.00
• Armature Pull-in Time (seconds): 0.050
• Backlash: 2.7
• Overall Height (K) mm: 30.0
• Mass (kg): 0.300
• Total Braking Energy (J): 17,000
• Coil Voltage (V): 24
• Coil Resistance (ohms): 80
• Coil Wattage (W): 7
• Standard Bore Sizes: 11
• MIN: 11
• MAX: 15
