Line Drawing - Click to Enlarge
Product Details
Configuration |
Bore Size d1 (small diameter) |
|
Bore Size d2 (large diameter) |
|
C (in) |
0.124 |
Outer Diameter D (in) |
0.945 |
Length (in) |
1.063 |
LF (in) |
0.354 |
Mass (lb) |
0.051 |
Max. Rotation Speed (min-1) (rpm) |
10,000 |
Misalignment Angular (degrees) |
1.5 |
Misalignment Axial (in) |
0.2 |
Misalignment Parallel (in) |
0.006 |
Width (S) (in) |
0.354 |
Torque Max. (ft lb) |
4 |
Nominal Torque (ft lb) |
1.8 |
